I NEED Series | LED Highbay 100W
Model Number : AHBL-100W


  • Unique design with private tooling, fashion and modern
  • Latest optics lens clip onto the structure, 0 screw in front
  • Patent water wave optics lens of transmission rate 95%,most accurate light output
  • Dust-free new housing gives out heat much faster and improves heat-disspation system

    • etl
    • ce
    • ctick
    • rohs
    • ip65
    • ik08
Save
Share
Inquire

Technical Data

Power100 W
Input Voltage90-305 VAC
PF>0.90@220 VAC
Dimming (Optional)3 in 1 dimming (PWM, 0-10V, Resistor) /Dali
CCT3000K / 4000K / 5000K / 5700K
System Efficiency130lmw / 160 lmw
Beam Angle60D / 90D / 120D
Operation Temp.-40℃ ~ +45℃
Storage Temp.-40℃ ~ +85℃
IP ClassIP65
IK ClassIK08
Product Size295*295*152mm
Packing Size334*145*340mm
Gross weight 3KG
Installation modeHook /Pendant /Bracket Mount

Downloads

  • Specification
  • IES file
  • AHBL-100W-60D-130LMW
  • AHBL-100W-90D-130LMW
  • AHBL-100W-120D-130LMW
  • AHBL-100W-90D-160LMW
  • AHBL-100W-120D-160LMW
